Lenovo ThinkPad L560 / L570 Battery (4400 mAh - 10.8V / 48Wh)

Description

The Green Cell 4400 mAh replacement battery is a top-quality power component specifically designed for the maintenance and refurbishment of Lenovo ThinkPad L560 and L570 professional laptops. Intended for IT repairers, corporate maintenance technicians, and PC refurbishing specialists, this spare part restores the original battery life of ThinkPad mobile workstations whose batteries are worn or faulty.

Electrochemicaly, this battery relies on an assembly of 6 high-density Lithium-ion (Li-Ion) cells from the Green Cell brand, offering a nominal capacity of 4400 mAh at a voltage of 10.8V (48 Wh). This architecture guarantees excellent voltage stability and supports up to 500 full charge and discharge cycles while maintaining over 80% of its initial capacity. The module features an intelligent electronic management board (BMS - Battery Management System) that constantly monitors charging parameters. This circuit provides active protections against overvoltage, overcharging, deep discharge, as well as thermal control in the event of abnormal computer heating.

The external casing is injected with a high-density ABS polymer resistant to heat and workshop mechanical stresses. Custom-designed according to the original manufacturer specifications, the chassis strictly respects the positioning of the connector pins and fixing rails. Installation is carried out by simple snapping onto the external bay of the ThinkPad PC, ensuring a firm mechanical hold without any structural play.

Technical specifications

• Manufacturer reference: LE88 (Green Cell / Equivalent FRU 00NY486, 00NY487, 00NY488, 00NY489)
• Technology / Material: Lithium-ion (Li-Ion) accumulators, ABS polymer rigid casing
• Compatibility: Lenovo ThinkPad L560 and L570 laptops
• Dimensions: 207 x 53 x 20 mm
• Weight: 300 g
• Power / Standards: Nominal voltage 10.8V (11.1V compatible) / Capacity 4400 mAh (48 Wh) / CE, RoHS certifications
• Number of cells: 6 Li-Ion cells
• Integrated protections: BMS with anti-overcharge, anti-overheating, short-circuit, and deep discharge security

Workshop Tip & Usage

Before returning the laptop to the end customer, the Workshop recommends performing an initial battery calibration cycle: charge the device to 100% on mains power, then let the battery discharge gradually to about 10-15% before recharging it fully without interruption. Avoid letting the accumulator drop below the 5% mark to preserve the internal chemistry of the Li-ion cells. During workshop storage before resale, make sure to keep the battery in a dry place at an ambient temperature between 15°C and 25°C, charged to about 50% of its capacity to avoid electrode passivation.
